C1812 - COLOUR DISPLAY LOGGER (Enabled)
DESCRIPTION
The C1812 is MoTeC's latest professional level Display Logger featuring an impressively generous, full colour screen. It comes standard with 250 MB internal logging memory and MoTeC's world-renowned i2 data analysis software. A Pro option is available for expert analysis.
C1812s now offer the convenience and flexibility of USB Logging, an optional upgrade that can be enabled in the field at any time. This upgrade also increases the internal memory to 500 MB. In addition, recently built models provide three composite video inputs for a live camera feed on the display screen.
The vivid 311mm screen (approx 12") is high resolution, ultra bright and anti-reflective for easy reading in direct sunlight. Choose from numerous selectable layouts and configure the channels, labels and colours to suit. Or, opt for the Display Creator upgrade and treat your screen as a blank canvas with unique graphics, images, logos and custom icons. Create multiple pages to suit different scenarios, optimising the screen space for your application.
SPECIFICATIONS
Motec | 18053 | Data Acquisition & Display
Display:
- Screen: Colour TFT LCD, anti-reflective
- Resolution: 1280 x 480, anti-aliased graphics
- Selectable fixed layouts with channel and label configurability
- 48 user-defined, scrollable message lines with programmable overrides
- 3 programmable 'pages', for example Practice, Warm-Up, Race
Logging
- 250 MB internal logging memory
- Optional USB Logging to a removable storage device (flash drive)
- includes upgrade to 500 MB internal memory
- Logging rates up to 1000 samples per second
- Fast Ethernet download
- Includes i2 Standard data analysis software (i2 Pro available as an upgrade)
Communications
- 4 x configurable CAN buses with individually programmable CAN bus speeds
- One can be used as RS232 Receive
- Two CAN buses support VIM/SVIM Expanders
- 2 x dedicated RS232 ports
Physical
- Dimensions 340.8 x 147.6 x 34 mm excluding connector, connector bosses and studs
- Weight 1.712kg
- 1 x 79 pin Autosport connector
- 1 x mini USB port
Inputs
- 10 x analogue voltage inputs (20 with I/O Upgrade)
- 4 x analogue temperature inputs (8 with I/O upgrade)
- 4 x digital inputs
- 2 x switch inputs
- 4 x speed inputs
- 3 x Composite Video Inputs for the connection of PAL or NTSC cameras
Outputs
- 6 x low side outputs
- PWM or switched operation
Internal Sensors
- 3-axis G sensor
- Dash temperature sensor
- Sensor supply voltage
- Battery voltage
Expanders
- Compatible with MoTeC E888 and E816 Expanders, providing full functionality.
- Compatible with VIM/SVIM Expanders
