D153 - COLOUR MINI DISPLAY
DESCRIPTION
MoTeC's mini colour display, the D153, features an anti-reflective, TFT LCD screen with exceptional brightness and clarity for easy viewing in strong sunlight.
Like the MDD it replaced, the D153 is an ideal size for steering wheel mounting and is designed to be controlled and configured by a MoTeC data logger. Numerous inputs are provided for buttons and dials, enabling the unit to activate functions in other CAN-based devices, such as traction control and pitlane speed limiting, with minimal wiring.
MoTeC's initial release provides fixed layouts and selectable channels, allowing users to choose the parameters they wish to monitor in various modes. Full screen configurability will be offered in future and most customers will be able to upgrade their existing unit via a software update.
Display Creator
Designed for use with MoTeC’s Colour Displays and Display Loggers, this intuitive and powerful software allows you to fully customise your onscreen graphics.
With Display Creator you can maximise the potential of your high resolution display by generating layouts specifically for your application. Add sponsor logos, design your own gauges, create unique warning screens, use non-English labels and define parameters to suit your individual needs.
Display Creator is free to download and comes with samples to get you started. D1 Series Displays do not require any enable to accept Display Creator files.
SPECIFICATIONS
Motec | 18027 | Data Acquisition & Display
Analogue Inputs
- Amount: 8 (can be used for switches or potentiometers)
- Measurement range: 0 V to 4 V
- Maximum operating voltage = 7.0 V *
- Maximum protected voltage = 32 V
- Input equivalent: 10 kΩ to 4.0 V
* Above this voltage other inputs may be affected.
Switch Inputs
- Amount: 6
- Threshold High max = 3.5
- Threshold Low min = 0.8 V
- Maximum operating voltage = 32 V
- Input equivalent: 10 kΩ to 4.0 V
Power Supply
- Operating voltage = 6.5 V to 32 V
- Operating current = 380 mA (typical) at 14 V, full brightness
- Reverse battery protected
Communications
- CAN 1 Mbit/sec
Display
- Type: TFT LCD, anti-reflective
- Screen size: 90 mm diagonal (3.54")
- Resolution: 320 x 240, anti-aliased graphics
- Brightness: controlled via CAN message, 100 steps
- Layouts: selectable fixed layouts
Operating Temperature
- Internal: -20 °C to 70 °C (above 60 °C maximum backlight brightness progressively reduced)
- Typical maximum ambient temperature in free air: 50 °C
Physical
- Weight: 200 grams (excluding wiring)
- Size: 96 x 71 x 23 mm (excluding wiring) (3.8 x 2.8 x 0.9")
- Anodised aluminium housing
